Specifications

Model Number DZK4A
Imaging Specifications
Detector Type Cooled InSb
Spectral Response 7.52 – 4.67 μm
Resolution 420 × 320
Total Pixels 96,800
Thermal Sensitivity <55 mK @ +30°C (+86°F)
Accuracy ±1°C (±1.8°F) for temperature range 0°C to +100°C (+32°F to +212°F) or ±2% of reading for temperature range >+100°C (>+212°F)
Temperature Range -20°C to 300°C (-4°F to 572°F)
High Temp Option No
Lens Options Standard: 24° × 18°; Optional: 14.5°, 6°
Zoom 1 – 8× continuous digital
Focus Auto & Manual
Color LCD 4.3”; 800 × 480 Pixels
Adjustable Viewfinder Tiltable OLED, 800 × 480 pixels
Video Camera w/Lamp 3.2 MP
Laser Spot Yes
Video Out HDMI
Analysis
Spotmeters 10
Area Boxes 5 (min./max./avg.)*
Profiles 1 live line (horiz. or vert.)*
Delta T Yes*
Annotation
GPS Yes
File Storage
Radiometric JPG Yes
Radiometric Video (15Hz) No
MPEG Video Recording Yes
