ISO standard corner, 178x162x118mm
Floor Beam for long side
Steel: CORTEN A, thickness: 4.0mm
Floor Beam for short side
Steel: CORTEN A, thickness: 4.5mm
Floor
28mm, intensity: 7260kg
Column
Steel: CORTEN A, thickness: 6.0mm
Inner column for back side
Steel: SM50YA + channel steel 13x40x12
Wall panel-long side
Steel: CORTEN A, thickness: 1.6mm+2.0mm
Wall panel-short side
Steel: CORTEN A, thickness: 2.0mm
Door Panel
Steel: CORTEN A, thickness: 2.0mm
Horizontal beam for door
Steel: CORTEN A, thickness: 3.0mm for standard container and 4.0mm for high cube container
Lockset
4 set container lock bar
Top Beam
Steel: CORTEN A, thickness: 4.0mm
Top panel
Steel: CORTEN A, thickness: 2.0mm
Paint
Inside wall paint thickness: 75µ Outside Wall paint thickness: 30+40+40=110u
Outside Roof paint thickness: 30+40+50=120u Chassis paint thickness: 30+200=230u

Modes of packing: SOC(shipper own container)
External Dimensions (L x W x H)mm: 6058x2438x2591
Internal Dimensions (L x W x H)mm: 5900x2352x2393
Door Dimensions (W x H)mm: 2340x2280
Max Gross Weight: 30480 KGS
Tare Weight: 2100 KGS
